Mitsubishi LT-5V
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco
Type: | Electronic Control Full Auto Player |
[Turntable part] | |
Drive system: | Phase-locked loop belt drive system |
Motorы: | DC servomotor |
[Platter part] | |
Diameter: | 304mm |
Material: | Aluminum alloy die cast |
Weight: | 1.3kg |
Inertial mass: | 300g / cm / S2 |
Number of revolutions: | 33-1/3, 45 rpm |
Rotational speed switching system: | Electronic type (Manual switching of abnormal rotational speed) |
Rotation speed fine adjustment range: | ±3% |
Wow and flutter: | 0.045% or less (WRMS) |
S / N ratio: | 65dB or more (IEC-B) 76dB or more (DIN-B) |
[Tonearm part] | Type - Static Balance Type / Universal / Straight Pipe Overall length - 223mm Effective length - 180mm Tracking error - ±0.1° Needle pressure adjustment - Direct reading type 0 to 2.5g (0.1g step) Head shell - Special resin with glass fiber Weight - 6.2g |
[Cartridge part] | Model- AT-12E (Audio Technica) Type - Dual moving magnet Stylus - 0.4 x 0.7 mil elliptical diamond Recommended tracking force - 1.5g Output level - 3.5mV (1kHz, 5 cm / s) Frequency response - 15Hz to 26kHz Channel separation - 23dB (1dB) Possible cartridge weight - 10 to 20g |
Automatic functions: | Auto lead-in, auto speed selection, auto size selection, auto cut (reject), repeat, auto lead-out, free movement left / right, cue prevention in absence of disc |
Features: | Stroboscopic speed indication Acoustic insulator feet Particle board cabinet, metallic finish Detachable protective polistyrol cover Stylus muting |
Included: | Overhang gauge Adapter for 45 rotations Driver |
Power supply: | AC 220V, 50 / 60Hz |
Power consumption: | 14W |
Dimensions (W x H x D): | 466 x 430 x 200mm |
Weight: | 11.5kg |
Year: | Around 1979 |
