Type: | Cartridgeless player system |
Motor synopsis: | Linear torque DC hall motor |
Drive system: | Direct-drive |
Control system: | Quartz PLL |
Rotational frequency: | 33 1⁄3 or 45rpm |
Rotational frequency precision: | 0.001% |
Rotation unevenness: | 0.003% (WRMS, the FG method) 0.015% (WRMS, the Japanese-Industrial-Standard record method) |
S/N: | 95dB (DIN-B) |
Starting torque: | 10kg/cm |
Startup property: | 0.3 second (33 1⁄3 rpm o'clock) |
Turntable: | Carrying out 32cm aluminum shaving appearance (weight of 2.8kg) |
Inertial mass: | 700kg/cm2 (it is an included about a rubber sheet) |
Tonearm: | Dynamic balance type twin pipe exchange system a straight-with integrated head shell pipe and S character type universal pipe |
Arm effective length: | 282mm |
Overhang: | 12.5mm |
Height adjustable range: | +8mm / -4mm |
Cabinet: | Brazi LeAnn Lowe's wood native wood eye |
Base material: | A barium sulfate (15mm), an aluminum alloy (10mm) |
Power source: | AC100V, 50Hz/60Hz |
Power consumption: | 10W |
Dimensions (W x H x D): | 600 x 278 x 445mm |
Weight: | 47kg |
Year: | 1983 |
