Type: | D / A converter |
Frequency response: | 2Hz to 20kHz ± 0.5dB |
S / N ratio: | 110dB or more |
Channel separation: | 100dB or more |
Total harmonic distortion factor: | 0.003% or less |
Analog output XLR type Balanced output: | 2.5V |
RCA coaxial unbalanced output: | 5V |
Digital input: | XLR type balanced digital input XLR type balanced BNC coaxial RCA coaxial TOS link type optical ST type optical Optical twin link terminal |
Digital output terminal: | BNC coaxial synchronous output |
Power supply: | AC 100V, 50Hz / 60Hz |
Power consumption: | 53W |
External dimension (W x H x D): | 475 × 140 × 425mm |
Weight Approximately: | 25kg |
Year: | 1993 |
