Type: | D/A converter |
Digital coaxial input terminal: | 2 lines (pin jack) |
Input signal level: | 0.5 V p - p ± 20% |
Input impedance: | 75Ω |
Twin link terminal: | Twin link jack |
Light wavelength: | 800 nm |
Fiber diameter: | 0.2 mm Reciprocating type |
Line output: | Terminal pin jack |
Output level: | 2.5Vrms (MSB) |
Number of channels: | 2-channel stereo |
Composite (D / A): | 16bit straight line |
Frequency response: | 10Hz to 20000Hz +0 - 0.5dB (Input digital signal sampling frequency: 44.1kHz or more) |
Harmonic distortion factor: | 0.003% or less (EIAJ) |
S / N ratio: | 110dB or more (EIAJ) |
Dynamic range: | 97dB or more (EIAJ) |
Channel separation: | 100dB or more (EIAJ) |
Power supply voltage: | AC 100V, 50Hz / 60Hz |
Power consumption: | 25W |
External dimensions (W x H x D): | 470 × 125 × 410mm |
Weight Approximately: | 17kg |
Year: | 1988 |
