Type: | D / A converter (digital audio processor) |
[D / A converter section] | |
System: | 20 bit full calibration D / A converter 20 bit • 8 times oversampling digital filter |
Sampling frequency: | 48kHz, 44.1kHz, 32kHz |
Frequency response: | 5Hz to 20kHz ± 0.5dB |
S / N ratio: | 106dB or more |
Dynamic range: | 100dB or more |
Total harmonic distortion factor: | 0.0005% (1kHz) |
Total harmonic distortion ratio: | Noise 0.0015% (1kHz) |
Channel separation: | 106dB or more |
[A / D converter section] | |
Method: | 16-bit auto calibration A / D converter 16 bit • 2 times oversampling digital filter |
Sampling frequency: | 48 kHz |
Frequency response: | 5 Hz to 22 kHz ± 0.5 dB |
S / N ratio: | 95dB or more |
Dynamic range: | 95dB or more |
THD factor: | 0.001% (1kHz) |
THD ratio: | Noise 0.003% (1kHz) |
Channel separation: | 85dB or more |
Input / output section: | Digital input - 75Ω coaxial / light (switching) x 3 Digital output - 75Ω coaxial / light (parallel) x 2 |
Line input: | Balanced - 50mV (-18dB, Rec level maximum) / 40kΩ Unbalance - 50mV (-18dB, Rec level maximum) / 25kΩ |
Line output (balanced): | Fixed - 2V (0dB) / 100Ω Variable - 2V (0dB, output level maximum) / 100Ω |
Line output (unbalanced): | Fixed - 2V (0dB) / 1kΩ Variable - 2V (0dB, Ouput level maximum) / 1kΩ |
Headphone output: | 100mW (0dB, Phones level maximum) / 40Ω |
Power supply: | AC 100V, 50Hz / 60Hz |
Power consumption: | Maximum 70W |
External dimensions (W x H x D): | 435 x 133 x 370mm |
Weight: | About 17.5kg |
Year: | 1989 |
