Type: | Reel To Reel Tape Recorder |
Track type: | 2 track 2 channels Recording / playback 4 track 2 channel playback |
Head configuration: | For Recording – SX sendust head For reproduction – SX sendust head × 2 For erasing – double gap ferrite head |
Tape speed: | 76 cm/s, 38 cm/s, 19 cm/s |
Motor capstan used: | Quartz lock electronic commutator DD drive system |
Reel portion: | Electronic commutator DD drive system × 2 |
Frequency response: | 76 cm / s – 30Hz to 35kHz 38 cm / s – 30Hz to 30kHz |
S/N ratio: | 62dB (JIS) |
Wow flutter 76 cm / s: | 0.010% (WRMS) |
Power supply: | AC 100V, 50Hz / 60Hz |
Power consumption: | About 135W |
Optional: | Head block RP-2224 (\ 38,000) Head block RP-2422 (\ 38,000) Head block RP-2224SX (\ 58,000) Head block RP-2422SX (\ 58,000) Remote control box RP-9690 (\ 13,000) Remote control box RP-9170 (\ 18,000) Wireless remote control unit RP-070 (\ 30,000) |
Outer dimension Transport section (W x H x D): | 500 × 443 × 347mm |
Weight transport section: | About 36kg |
Outer dimension Amplifier section (W x H x D): | 500 × 223 × 389mm |
Weight Amplifier section: | Approximately 16.6kg |
Year: | 1979 |
