Type: | Reel to Reel Tape Recorder |
Track system: | Auto reverse, 4-track, 2-channel, stereo system |
Heads: | 2 x erase/record 2 x playback |
Motor: | 2 x reel 1 x capstan |
Tape speeds: | 3 3⁄4, 7 1⁄2, 15 ips |
Reel size: | Up to 10.5 inch reel |
Equalization: | NAB |
Wow and flutter: | 0.018% (38 cm / s, 15 ips) |
Frequency response: | 30Hz to 30kHz (± 3dB) |
Signal to Noise Ratio: | 57dB |
Total harmonic distortion: | 0.8% |
Input: | 60mV (line) 0.25mV (mic) |
Output: | 0.775V (line) |
Power supply: | AC 100V, 50Hz / 60Hz, DC 24V |
Power consumption: | About 80W |
Dimensions (W x H x D): | 492 x 443 x 257mm |
Weight: | 26.5kg |
Optional: | Head block RP-2R2R (\ 48,000) Head block RP-2R2RHF (\ 98,000) Dust cover RP-9110 (\ 5,000) Battery adapter RP-086 (\ 30,000) Remote control box RP-9170 (\ 18,000) Wireless remote control unit RP-070 (\ 30,000) |
Year: | 1979 |
