FOSTEX Model 80

Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco

Item Lorem ipsum dolor sit amet. Item Lorem ipsum dolor sit amet. Item Lorem ipsum dolor sit amet.
Item Lorem ipsum dolor sit amet. Item Lorem ipsum dolor sit amet. Item Lorem ipsum dolor sit amet.
Item Lorem ipsum dolor sit amet. Item Lorem ipsum dolor sit amet. Item Lorem ipsum dolor sit amet.

Technic details

Specifications

Type:
8 Track Recorder / Reproducer
Track system:
8 track, 8 channel (8 channel record, 8 channel reproduce)
Tape format:
¼” tape width, 1 mil base
Heads:
1 x Recording head
1 x Playback head
1 x Erase head

Motors:
2 x For Reel drive
1 x For Capstan drive
Reel size:
7" reel
Tape speeds:
38.1 cm /s, ±0.5% (15 ips)
Pitch control:
±10%
Wow & flutter:
0.06% peak (IEC / ANSI), weighted for 38.1 cm /s, measured with flutter test tape
Starting time:
Less than 0.5 sec.
Fast wind time:
140 sec. for 1800 ft. of tape
Frequency response:
40Hz to 18kHz, ±3dB (38.1 cm /s)
Record level calibration:
0dB referenced to 320 nWb / m of tape flux
Equalization:
35µs (At 38.1 cm /s)
Signal to Noise Ratio:
72dB Weighted (For 38.1 cm /s, referenced to 3% T.H.D. level (10dB above 0dB) at 1kHz))
60dB Unweighted (For 38.1 cm /s, referenced to 3% T.H.D. level (10dB above 0dB) at 1kHz))
Total harmonic distortion:
Less than 1% (At 1kHz, 0 VU)
Erasure:
Better than 70dB (At 1kHz)
Input / Impedance:
0.3V (-10 dBV) / 30kΩ, unbalanced (Line)
Output / impedance:
0.3V (-10 dBV) / 10kΩ or higher, unbalanced (Line)

Power requirements:
AC 120V, 55Hz (U.S.A. / Canada models)
AC 220V, 55Hz (European models)
AC 240V, 55Hz (U.K. / Australian models)
Power consumption:
60W (All models)
Dimensions (W x H x D):
356 x 343 x 171mm
Weight:
13kg
Year:
1985
