Type: | Tape Recorder |
Track system: | 4 track 2 channel stereo system |
Reel: | 26 shape (No. 10) |
Tape speed: | 19 cm / s (± 0.8%) 9.5 cm / s (± 1.0%) |
Wow • Flutter: | 0.03% Wrms (19 cm / s) 0.04% Wrms (9.5 cm / s) |
Frequency characteristic (When using EE position tape): | 25Hz to 33kHz ± 3dB (19 cm / s) 25Hz to 25kHz ± 3dB (9.5 cm / s) |
Distortion factor: | 0.5% or less (1 kHz, third harmonic distortion ratio) |
S / N ratio: | 65dB (19 cm / s) |
Heads: | GX recording head x 2 GX playhead x 2 Erase head x 2 |
Motors: | AC servo direct capstan motor x1 AC Eddie Current reel motor x 2 |
Fast-forward rewind time: | Approximately 75 seconds (when using No. 10 reel 360 m tape) |
Input level: | Microphone - 0.25mV Line - 70mV |
Output level line: | 0.775V |
Headphone: | 0mV to 100mV |
Power supply voltage: | AC 100V, 50Hz / 60Hz |
Power consumption: | 75W |
Supplied: | Connection cord x 2 pairs Empty reel x1 Sensing tab kit x 1 set 1 pair of reel hub adapter |
Optional: | Wired remote control RC-21 (¥ 6,000) |
External dimensions (W x H x D): | 440 x 483 x 256mm |
Weight: | 21kg |
Year: | 1981 |
