Type: | Stereo control console |
Rated output / impedance Flat Out: | 1.5V / 50Ω |
Input sensitivity / impedance: | Phono 1 - 2.5mV / 47kΩ, 100kΩ Phono 2 - 2.5mV / 47kΩ AUX - 150mV / 47kΩ |
Input Equivalent Noise “A” Weighted: | 0.15μV |
Total harmonic distortion factor: | 0.002% or less |
Frequency response (MM Cartridge): | 20Hz to 100kHz (RIAA +- 0.2dB) |
Frequency response (AUX): | 10Hz to 100kHz (Flat out + 0 - 0.2dB) |
S/N ratio: | MM Cartridge - 90dB (“A” Weighted, 7.75mV input) AUX - 100dB (INF-A, 775mV input) |
Power Requirements (E Version): | AC 110/120/220/240V, 50/60Hz |
Power Consumption: | 80W |
Outside dimension (W x H x D): | 483 × 117.5 × 441mm |
Weight: | 13.5kg |
Year: | 1981 |
