Type: | Control amplifier |
[Input sensitivity / impedance] | Tuner, CD, Line 1 to 3: 150mV / 50kΩ Balance Line 1/2: 150mV / 100kΩ |
[Output level / impedance] | |
Coaxial: | Nominal 1V / 300Ω Up to 7.5V |
Balance: | Nominal 1V / 600Ω Up to 7.5V |
Total Harmonic Distortion Ratio: | 0.005% or Less (Rating) |
Frequency response: | 20Hz to 20kHz, +0 -0.1dB |
S / N ratio: | 110dB or more |
[Tone control] | |
Treble: | Turnover 3kHz, up to ± 8dB, 10kHz, ±6dB |
Bass: | Turnover 300Hz, maximum ± 8dB, 100 Hz, ±6dB |
Attachment device: | Tape dubbing 2 lines (1 → 2, 2 → 1) Rec off Straight switch Output mode selector switch Remote (Power) output Line Phase Sensor Output phase selector switch |
Power supply voltage: | AC 100V, 50Hz / 60Hz |
Power consumption: | 38W (Electrical Appliance and Material Control Law) |
Maximum external dimensions (W x H x D): | 467 x 187 x 435mm |
Weight: | 18kg |
Year: | 1996 |
Upgrade to other C7i: | ¥ 50,000 |
