Type: | Control amplifier |
Output voltage Pre out: | 1V (rated), 12V or more (maximum) |
Output impedance Pre out: | 47Ω |
Total harmonic distortion ratio: | Phono 1, 2 - 0.03% or less (Rec out: 2V, 1kHz) DAD, Monitor 1, 2 - 0.05% or less (Pre out: 2V, 1kHz) Tuner, Line - 0.002% or less (Pre out: 2V, 1kHz) |
Frequency response: | Phono 1, 2 - 20Hz to 20kHz ± 0.2dB DAD, Monitor 1, 2 - 1Hz to 50kHz ± 0.5dB Tuner, Line 1, 2 - 1Hz to 50kHz ± 0.5dB |
Input sensitivity (output 1V): | Phono MM - 2mV Phono MC - 100μV DAD, Monitor 1, 2 - 150mV Tuner - 150mV (with input level set) Line - 150mV |
Input impedance: | Phono 1, 2 - 50kΩ, 100kΩ DAD, Monitor 1, 2 - 100kΩ Tuner - 50kΩ Line - 100kΩ |
S/N ratio (IHF-A correction): | Phono 1, 2 - 90dB or more DAD, Monitor 1, 2 - 110dB or more Tuner, Line - 110dB or more |
Accessory: | Monitor switch (Tape 1, Tape 2) Tape dubbing switch (1to 2, 2 to 1) Recording switch Phono function switch (Phono 1, Phono 2) Signal off switch Line Phase Sensor |
Power supply voltage: | AC 100V, 50Hz / 60Hz |
Power consumption: | 40W (Electrical Appliance and Material Control Law) |
Option: | Wood case W - 05C (\ 50,000) Rack mount adapter LM - 05C (\ 15,000) |
External dimensions (W x H x D): | 460 × 135 × 442mm |
Weight: | 11kg |
Year: | 1983 |
