Type: | Mono pre amplifier with separated power supply |
Bandwidth: | 20Hz to 50kHz (line) RIAA (phono) |
Number of blocks: | 4 (two mono pre amplifier + two separated power supply) |
[Phono section MC] | |
Sensitivity: | 160mkV (2 V at the output) |
Input impedance: | 100 ohms |
Gain at 1 kHz: | > 75dB |
Saturation level: | 20 mV (before clipping at 1 kHz) |
S / N to a no balanced nominal sensitivity: | 56dB |
Distortion at 2V: | < 0.l% |
[Phono section MM] | |
Sensitivity: | 2mV (2 V at the output) |
Input impedance: | 47.8 kohms |
Gain at 1 kHz: | 59dB |
Overload level: | 48mV (before clipping at 1kHz) |
S / N to a no balanced nominal sensitivity: | 62dB |
Distortion at 2V: | 0.l% |
[Auxillary section] | |
Sensitivity: | 120mV (2 V at the output) |
Gain at 1 kHz: | 25dB |
S / N to a no balanced nominal sensitivity: | 80dB |
Distortion at 2V: | more 0.l% |
Inputs: | 4 x line, 1 x MM phono, 1 x MC phono, 1 x tape monitor |
Tubes pre amplifier (1 pc): | 6 x ECC83, 1 x ECC88 |
Tubes power supply (1 pc): | 1 x EF86, 1 x EL86 |
Consumption: | 65 W (one channel) |
Dimensions (W x D x H): | 4 chassis of 43 x 34.5 x 17.5cm |
Weight: | 33.56kg (Mono pre amplifier with separated power supply) |
