Type: | Stereo preamplifier |
Frequency response: | 10Hz to 100kHz |
Total harmonic distortion: | 0.002% |
Input sensitivity: | 0.125mV (MC) 2.5mV (MM) 150mV (line) |
Signal to noise ratio: | 76dB (MC) 86dB (MM) 100dB (line) |
Channel separation: | 70dB (MM) 75dB (line) |
Output: | 1.5V (Pre out) 23V (Pre out Max) |
The main use parts: | Transistor: 171 pieces FET: 80 pieces IC: 11 pieces Diode: 123 pieces Rectification stack: One piece Reed relay: Eight pieces Relay: Two pieces |
Power supply voltage: | AC100V, 50Hz/60Hz |
AC outlet Power-switch linkage: | Three lines, Total 210W |
Power-switch un-interlocking: | Two lines, Total 700W |
Power consumption: | 90W |
Dimensions (W x H x D): | 455 x 134 x 392mm |
Weight: | 14.3kg |
Year: | 1982 |
