Type: |
Stereo control center |
Frequency response: | High-level input - It is +0 20Hz - 20000Hz -0.2dB Disc input - 20Hz-20000Hz ±0.2dB |
THD: | 0.005% (for 20Hz - 20kHz, Output power) |
Input sensitivity/input impedance: | DISC1, 2 (Head Amp OFF) - 2.0mV/100 ohm, 47kohm, 82kohm, a 150kohm change DISC1, 2 (Head Amp ON) - 0.1mV/100ohm fixation Tuner, AUX, Tape Play1, 2 - 126mV/50kohm |
An Output power/Output load impedance: | Output - 2.0V/2 ohm Tape Rec1, 2 - 126mV/500 ohms |
Minimum load impedance: | Outputs - 1kohm Tape Rec - 10kohm |
Gain Tuner, AUX, and Tape Play: | Tape Rec - 0dB Outputs - 24dB HeadPhones - 20dB |
Gain DISC (Head Amp OFF): | Tape Rec - 36dB Outputs - 60dB HeadPhones - 56dB |
S/N / Input conversion noise: | High-level input - 110dB / -128dBV Disc input (Head Amp OFF) - 85dB / -139dBV Disc input (Head Amp ON) - 72dB / -152dBV |
Tone control (The change type by 8 step push switch): | Low-pitched sound - 500Hz : ±8dB (50Hz) 2dB step, 200Hz : ±8dB (20Hz) 2dB step Loud sound - 2kHz : ±8dB (20kHz) 2dB step, 7kHz : ±8dB (50kHz) 2dB step |
Attenuator: | - A 10dB -20dB-30dB change type |
Subsonic Filter: | 17Hz, 12 dB/oct |
The semiconductor used: | 159Tr 10FET 102Di |
Power consumption: | 80W |
Dimensions (W x H x D): | 466 x 188 x 391mm |
Weight: | 18kg |
Year: | 1978 |
