Type: | Linear-phase 3-Way 3 Speaker System |
Method: | Bass-reflex scheme, floor type |
Use unit For low-pass (EAS-46PL01S): | 46cm cone type |
For mid range (EAS-10HM03-N): | 10cm horn type |
For high regions (EAS-35HD04SA): | 10cm horn type |
Reproduction frequency band: | 30Hz to 22kHz - 10dB |
Impedance: | 6Ω |
Output sound pressure level: | 95dB / W / m |
Permissible input: | 300W (MUSIC) 200W (DIN RMS) |
Crossover frequency: | 700Hz, 6.5kHz |
The volume of the body of the low-frequency section is: | 300 liters |
External dimensions (W x H x D): | 1115 × 1200 × 705mm (with net) |
Weight: | 140kg (with net) |
Year: | 1977 |
