Type: | Horn type super tweeter (crossover network internal organs) |
Maximum input: | 20W (RMS) |
Frequency characteristics: | 10kHz to 40kHz |
Input impedance: | 6 ohms |
Input sensitivity: | 95dB (max) (2.83V/1m) |
Cut off frequencies: | 16kHz (-18db/oct) |
Driver: | Compression driver mounted which adopted the JBL tradition of pure titanium diaphragm |
Diameter: | 19mm (3/4 inch) |
Magnet: | neodymium |
Dimensions (W x H x D): | 107 x 67 x 166 (including terminals) |
Net weight: | 850g |
