Type: | Channel divider |
[Maximum input level] | |
Balanced: | 7V, XLR type (strain rate 0.01% or less, 20Hz to 20kHz) |
Unbalanced: | 7V, RCA (strain rate 0.01% or less, 20Hz to 20kHz) |
Total harmonic distortion rate: | 0.003% (20Hz to 20kHz, output 2V) |
Frequency characteristics: | 20Hz to 20kHz + 0 - 0.2dB (single channel equivalent band) 0.5Hz to 300kHz + 0 -3dB (single channel equivalent band) |
Gain: | 0dB |
Standard frequency: | 21 points |
Crossover characteristic: | -3dB ± 5% |
Slope characteristics: | -12dB / oct, -18dB / oct, -24dB / oct |
Switch: | Switching type |
Input impedance: | Balanced - 40kΩ (20kΩ / 20kΩ) Unbalanced - 20kΩ |
Output impedance: | Balanced - 50Ω (25Ω / 25Ω) Unbalanced - 50Ω |
S / N: | 100dB (output 0.5V, IHF-A correction) |
Minimum load impedance: | Balanced - 600Ω Unbalanced - 600Ω |
Level adjustment: | 0dB to -20.5dB, 1dB steps and ∞ |
Power supply voltage: | AC 100V / 117V / 220V / 240V, 50Hz / 60Hz |
Power consumption: | 32W |
Optional: | Line amplifier / unit LA - 25 (¥ 50,000) Filter Amplifier Unit DN - 25 (¥ 50,000) Frequency board (¥ 15,000 each) |
Model number crossover frequency: | FB-70 70Hz, FB-100 100Hz, FB-130 130Hz, FB-180 180Hz, FB-250 250Hz, FB-290 290Hz, FB-300 300Hz, FB-350 350Hz, FB-500 500Hz, FB-650 650Hz, FB-800 800Hz, FB-1000 1kHz, FB-1200 1.2kHz, FB-1800 1.8kHz, FB-2500 2.5kHz, FB-3500 3.5kHz, FB-5000 5kHz, FB-7000 7kHz, FB-8000 8kHz, FB-10000 10kHz, FB-12500 12.5kHz |
Maximum external (W x H x D): | 475 x 170 x 380mm |
Weight: | 16kg |
Year: | 1992 |
