Type: | Player |
Disc format: | CD |
Type Pick-up: | Astigma 3-beam |
Objective lens suspension: | Twin parallel suspension |
Light source: | Semiconductor laser |
Wavelength: | 800 nm |
Digital converter: | AN6806, 16-bit linear |
CD Mechanism: | SRUD010N01Z |
Control keys: | Basic keys - 7 Program keys - 14 |
Dics loading: | Front type, automatic loading |
Sampling frequency: | 44.1kHz |
Error correction method: | Technics Super decoding algorithm |
Frequency response: | 4Hz to 20kHz |
Dynamic range: | More than 90dB |
Signal to Noise Ratio: | More than 90dB |
Channel separation: | More than 90dB |
Total harmonic distortion: | 0.004% or less (1 kHz, 0 dB) |
Wow flutter: | Quartz Accuracy |
Output voltage / impedance: | 1.5V / 220ohms |
Power supply: | AC 110 / 120 / 220 / 240V, 50Hz / 60Hz |
Power consumption: | 60W |
Dimensions (W x H x D): | 430 x 315 x 145mm |
Weight: | 10kg |
Year: | 1983 |
