Type: | CD Transport |
Type disc: | CD |
Reading method: | Non-contact optical reading (using semiconductor laser) |
Laser: | GaAlAs double hetero diode λ = 780 nm |
Rotation speed: | Approximately 500 to 200 rpm (CLV) |
Error correction method: | Sony Super Strategy Cross interleaved Reed Solomon code |
Number of channels: | 2 channels (stereo) |
Output terminal: | COAXIAL (pin jack) - 0.5Vp-p / suitable connection impedance 75Ω BALANCED (equivalent to XLR - 3) - 2.5V / conformity connection impedance 110Ω BNC (BNC connector) - 2.5V / applicable connection impedance 75Ω |
Optical system: | OPT 1 (Toss link type): -18dBm (emission wavelength 660nm) OPT 2 (ST link type): -18dBm (emission wavelength 800nm) TWIN LINK: -18dBm (emission wavelength 800nm) |
Input terminal: | SYNC IN (BNC connector) - Input impedance 75Ω |
Power supply: | AC 100 V, 50/60 Hz |
Power consumption: | 30W |
Attached: | Remote Commander RM - R 10 Remote Commander RM - A 10 |
External dimensions (W x H x D): | 475 × 145 × 410mm (When the disk compartment is opened, the height (H) is 295mm) |
Weight Approximately: | 30 kg |
Year: | 1993 |
