Type: | SACD/CD player |
Correspondence format: | SACD, compact disk, CD-Recordable/RW |
Pickup: | Optical twin laser |
Transport Laser Beam Wavelength: | 650nm (SACD) / 790nm (CD) |
Laser Power: | CLASS IIa/CLASS I |
Digital analog converter: | Multiple bit type |
Play frequency band: | SACD - 4Hz-110kHz, +0.5 -2dB CD - 4Hz-20kHz, ±0.5dB |
S/N ratio: | 110dB or more |
Dynamic range: | 100dB or more |
THD: | SACD - 0.002% CD - 0.003% |
Fixed Output level: | 2 Vrms Unbalanced 4 Vrms Balanced |
Variable Output level: | 0 - 6 Vrms Unbalanced 0- 12 Vrms Balanced |
Output Impedance: | 600 ohms Unbalanced and Balanced |
Channel Separation: | Better than 98dB (1,000Hz) |
Digital output termination: | Coaxial - One line Light - One line |
Digital output: | Optical - 15dbm to -21dbm (CD and MP3) Coaxial - 0.5V p-p/75 ohm (CD and MP3) |
Sampling Frequencies: | 44.1kHz (CD and MP3) |
Analog output terminal: | RCA - One line (a fixture/variable) XLR - One line (a fixture/variable) |
Power Requirements: | 100 Volts, 50/60Hz 110 Volts, 50/60Hz 120 Volts, 50/60Hz 220 Volts, 50/60Hz 230 Volts, 50/60Hz 240 Volts, 50/60Hz |
[Note: Refer to the rear panel of the MCD201 for the correct voltage] |
Power consumption: | 35W |
The maximum Dimensions (W x H x D): | 445 x 152 x 419mm |
Weight: | 10.4kg |
Adjunct: | Wireless remote control |
* CD-Recordable/RW may be unreproducible depending on a recording mode or a media |
