Type: | Player |
Supported disc: | CD |
Analog output unbalance (RCA): | 1 x line 1 x headphone (volume control available) |
Digital Outputs: | One coaxial (RCA) line One light (TOS - LINK) line |
DAC: | Burr-Brown 192KHz/24bit |
Output voltage: | 2V |
Frequency response: | 4Hz to 20kHz |
Total harmonic distortion rate: | 0.004% |
S / N ratio (IHF-A): | 95dB |
Use vacuum tube: | ECC 82 (12 AU 7) × 1 |
Accessory: | Remote control (RA-N3) Power supply cable (JPA-10000) |
Remote control function: | Power supply, playback operation key, disc eject key, time display switching, display dimm special playback key (track order program / random / repeat / A - B repeat / intro / recall play), amp volume operation (corresponding amplifier only) |
Power supply voltage: | AC 100V (50/60Hz) |
Power consumption: | 20W (according to the Electrical Appliance and Material Safety Law) 0.1W (at standby) |
External dimension (W x H x D): | 400 x 168 x 280mm (Do not include terminal and knob for depth) |
Weight: | 9kg (main unit) |
