Type: | 3-head, single elcaset deck |
Track System: | 4-track, 2-channel stereo |
Tape Speed: | 9.5 cm/s |
Heads: | 1 x playback (super permalloy head) 1 x recording (super permalloy head) 1 x erasure (double-gap ferrite head) |
Motor: | FG servo controlled DC motor |
Tape Type: | Type I, FeCr, Cr02 |
Frequency Response: | 25Hz to 20kHz +-3dB (tape type I) 25Hz to 22kHz +-3dB (tape FeCr and Cr02) |
Signal to Noise Ratio: | 60dB (tape type I, 315Hz peak level) 63dB (tape FeCr and Cr02, 315Hz peak level) |
Wow and Flutter: | 0.06% (WRMS) |
Total Harmonic Distortion: | 0.8% (tape Cr02) |
Input / Impedance: | 60mV / 100kohms (line) 0.25mV / applicable impedance 400ohms-20kohms (mic) |
Outputs / Impedance: | 0.58V / 22kohms over (line) 60mV / 8ohms (Headphone) |
Power requirement: | 110 / 125 / 220 / 240V, 50/60Hz |
Power consumption: | 45W |
Dimensions: | 483 x 253 x 350mm |
Weight: | 14kg |
Year: | 1977 |
