Type: | 3-head, single compact cassette deck |
Track System: | 4-track, 2-channel stereo |
Tape Speed: | 4.76 cm/s |
Fast Winding Time: | 90 sec. for C-60 |
Heads (ferrite): | 1 x record, 1 x playback, 1 x erase |
Motor: | 1 x DC servomotor, synchronization 0.07% |
Type of Tape: | Cassette tape, C-60 and C-90 (Philips type) |
Tape Type: | Normal, CrO2, Metal |
Frequency response: | Normal - 30-14000Hz CrO2 - 30-16000Hz Metal - 30-17000Hz |
Noise Reduction: | Dolby-B |
External interference distance: | 57dB / with Dolby B 67dB |
Wow and Flutter: | Playback 0.10% (WRMS) Record/Playback 0.25% (RMS) |
Channel Separation: | 30dB min. (at 1kHz) |
S/N ratio (Playback): | 47dB min. |
Erase Efficiency: | 65dB min. |
Total Harmonic Distortion: | 2.5% (Normal) |
Inputs and outputs: | 1x Cincheingang / 1xCinchausgang, 1x DIN (input and output), 2x Micro (Mono L / R), 1x headphones |
Equipment: | Auto-bias system, tape counter, memory circuit, Rec-mute |
Dimensions (W x H x D): | 475 x 150 x 397mm |
Weight: | 19.8kg |
