Type: | 3-head, single compact cassette deck |
Track System: | 4-track, 2-channel stereo |
Tape Speed: | 4.75 cm/s |
Heads: | 1 x combination record/playback, 1 x erase |
Motor: | 1 x reel, 1 x capstan |
Noise Reduction: | B |
Tape Type: | Normal, FeCr, CrO2, Metal |
Frequency response: | 20Hz to 20kHz (Metal tape) |
Signal to Noise Ratio: | 69dB (dolby B) |
Wow and Flutter: | 0.03% |
Total Harmonic Distortion: | 1.0% |
Input: | 60mV (line) 0.3mV (mic) |
Output: | 0.45V (line) |
Semiconductors: | 139 x transistors 125 x diodes 22 x IC |
Dimensions: | 475 x 150 x 397mm |
Weight: | 19.8kg |
Year: | 1980 |
