Type: | Compact cassette tape deck |
Recording Head: | Ribbon sendust head |
Reproducing Head: | Ribbon sendust head |
Erase Head: | Special composition head |
Motor: | For a constant-speed drive - quartz PLL direct-drive scheme coreless capstan motor For the reeled live - high torque coreless motor |
It is already volume time: | 75 or less (C-60) seconds |
Rotation unevenness: | 0.03% or less (WRMS) |
[Frequency characteristic] | |
STD, LH tapes: | 20Hz - 19kHz, 25Hz-16kHz ±3dB (at the time of a -20dB sound recording) |
FeCr tapes: | 20Hz - 20kHz, 25Hz-18kHz ±3dB (at the time of a -20dB sound recording) |
Chromium tapes: | 20Hz - 20kHz, 25Hz-18kHz ±3dB (at the time of a -20dB sound recording) 20Hz - 13kHz (at the time of a 0dB sound recording) |
Metal tapes: | 20Hz - 20kHz, 25Hz-19kHz ±3dB (at the time of a -20dB sound recording) 20Hz - 15kHz (at the time of a 0dB sound recording) 30Hz-15khz ±1dB (It is about AutoBLE at the using time. At the time of a 20dB sound recording ) |
S/N ratio: | (3% of 3rd THD) |
Auditory sensation weighting: | Dolby off - 60dB or more Dolby on - 70dB or more (5kHz or more) |
Distortion: | 1.0% or less (0dB) |
Input sensitivity: | Line - 65mV, Mic - 0.3mV |
Normal-output level: | Line - 450mV, Headphone - 63mV |
Supply voltage: | AC100V, 50Hz/60Hz |
Power consumption: | 45W |
Dimensions (W x H x D): | 420 x 217 x 390mm |
Weight: | 18kg |
Year: | 1980 |
