Type: | 2-head, single compact cassette deck |
Truck System: | 4-track, 2-channel stereo |
Motor: | A DC servo motor with tachogenerator |
Magnetic heads: | 1 x record/playback (Hard-permalloy) 1 x erase (Ferrite) |
Magnetic tape velocity: | 4.75cm/s |
Recording System: | AC bias (85kHz) |
Erasing System: | AC erasing (85kHz) |
Fast forward / rewinding time: | At C-60 tape about 90 seconds |
Tape Type: | Normal, CrO2 |
Noise Reduction: | Dolby NR |
Wow and flutter: | 0.07% (WRMS) |
Frequency response: | 40Hz - 12.5kHz (normal tape) 40Hz - 14kHz (CrO2 tape) |
Signal to noise ratio: | Dolby NR out - 56dB (RMS) Dolby NR in - 64dB (RMS) |
Equalizer curve damping time constant: | 3,180 microsec. / 120microsec. (normal tape) 3,180 microsec. / 70microsec. (CrO2 tape) |
Input level / impedance: | Mic - 0.3mV / 2.2kohm Line - 80mV / 90kohm DIN - 0.44V / 22kohm |
Output level / impedance: | Line - 0.44V / 22kohm Headphone - 0.8mW/8ohm DIN - 0.44V / 22kohm |
Power source: | AC 100V, 50Hz/60Hz |
Power consumption: | 9W |
Dimensions (W x H x D): | 480 x 154 x 323mm |
Weight: | 5.3kg |
Year: | 1978 |
