Type: | 2-head, single compact cassette deck |
Track System: | 4-track, 2-channel stereo |
Transport: | Belt Drive (Capsŧan) Sìngle Capsŧan Transport Auto Shutoff Mechanical Tape Loading |
Motors: | 1 x DC Servo |
Tape Speed: | 4.75 cm/s |
Heads: | 1 x record/playback (Super Hard Permalloy Head) 1 x erase (Ferrite Head) |
Tape Type: | Type I, FeCr, CrO2 |
Noise Reduction: | Dolby-B |
Frequency characteristic: | 40Hz at 12.5kHz (Type I tape) 40Hz at 15kHz (CrO2 tape) 40Hz at 16.5kHz (FeCr tape) |
Wow and flutter: | DIN - 0.17% WRMS - 0.08% |
THD: | 0.08% (WRMS) 0.17% (DIN) |
Inputs: | Microphone – 2 (mono) RCA connector |
Outputs: | Headphones RCA connector |
Display: | Analog Needle Meters 3-Digıt Mechanical Counter |
Peak indication system: | 2 x Vumeters |
Exterior: | Front Loading Orientation Left Champagne Finish Silver Finish |
Power supply: | AC 110 / 120 / 220 / 240V, 50/60Hz |
Dimensions (W x H x D): | 416 x 146 x 239mm |
Weght: | 6kg |
Year: | 1979 |
