Type: | 2-head, single compact cassette deck |
Track System: | 4-track, 2-channel stereo |
Tape Speed: | 4.75, 9.5 cm/s |
Heads: | Record/playback (Sendust Alloy) x 1 Erase (Ferrite) x 1 |
Motor: | DC servo x 2 |
Tape Type: | Ferric Oxide, FeCr, CrO2, Metal |
Noise Reduction: | Dolby-B Noise Reduction MPX Filter |
[Overall Frequency Response] | |
Tape Speed - at 20dB for 4.75 cm/s: | Ferric Oxide Tape - 25Hz to 16kHz (± 3dB) CrO2 Tape - 25Hz to 17.5kHz (± 3dB) FeCr Tape - 25Hz to 18kHz (± 3dB) Metal - 25Hz to 18.5kHz (± 3dB) |
Tape Speed - at 10dB for 9.5 cm/s: | Ferric Oxide Tape - 25Hz to 18.5kHz (± 3dB) CrO2 Tape - 25Hz to 19kHz (± 3dB) FeCr Tape - 25Hz to 19.5kHz (± 3dB) Metal - 25Hz to 20.5kHz (± 3dB) |
Fast Rewing / Forward Time: | 60s |
Wow and Flutter: | Tape Speed 4.75 cm/s - 0.1% Tape Speed 9.5 cm/s - 0.07% |
Total Harmonic Distortion: | Ferric Oxide Tape - 2% CrO2 Tape / FeCr Tape / Metal - 2.5% |
Semiconductors: | 91 x transistors 71 x diodes 7 x IC 8 x LED |
Power supply voltage: | E/N versions - AC 110/220V, 50/60Hz T/A versions - AC 220/240V, 50/60Hz |
Power consumption: | 63W |
Dimensions (W x H x D): | 416 x 146 x 243mm |
Weight: | 9.1kg |
Year: | 1980 |
