Type: | 3-head, single compact cassette deck |
Track System: | 4-track, 2-channel stereo |
Tape Speed: | 4.75 cm/s |
Heads: | 1 x record, 1 x playback, 1 x erasure |
Motors: | For capstans - Direct drive FG servo DC x 1 For reels - DC x 1 For head housing lifts - DC x 1 |
Tape Type: | Normal CrO2 Metal |
Noise Reduction: | B, C |
Frequency Response: | 15Hz to 27kHz (Metal tape) |
Signal to Noise Ratio: | 73dB (dolby C) |
An attached functionality: | Auto calibration Line phase sensor Others |
Wow and Flutter: | 0.022% |
Rolling-up time: | 80 or less (FF-REW is at C60) seconds |
Total Harmonic Distortion: | 0.5% |
Input: | 100mV (line) |
Output: | 0.55V (line) |
Power consumption: | 40W |
Dimensions (W x H x D): | 460 x 158 x 361mm |
Weight: | 11.5kg |
Optional: | Wireless remote control AK-10 (¥ 7,000) Wireless remote control AK - 20 (¥ 18,000) |
Year: | 1983 |
