Type: | Elcaset Tape Deck |
Head recording: | Ferrite (AF) head × 2 |
Head Erase: | Ferrite (AF) head × 1 |
Motor: | DC servo motor × 1 Coreless motor × 2 |
Wow and flutter: | 0.04% (WRMS) |
Frequency response (Dolby NR off): | 15 Hz to 25 kHz (Type I LH) 15 Hz to 27 kHz (Type II DUAD) |
S / N ratio (Type I LH, peak level): | 67 dB (Dolby NR on) 59 dB (Dolby NR off) |
Input sensitivity / impedance: | Line in: 95mV / 100kΩ Mic: 0.3mV / 300Ω to 10kΩ |
Output impedance (load): | Line out: 50kΩ or more Headphone: 8Ω to 32Ω |
Power supply voltage: | AC 100V, 50Hz / 60Hz |
Power consumption: | 35W |
External dimensions (w x H x D): | 435 × 168 × 317mm |
Weight: | 12.5 kg |
Year: | 1979 |
