Type: | 3-head, single compact cassette deck |
Track System: | 4-track, 2-channel stereo |
Tape Speed: | 4.76 cm/s |
Heads: | 1 x record, 1 x playback, 1 x erase |
Motors: | 2 x Motor Mechanism |
Tape Type: | Normal, FeCr, CrO2, Metal |
Fast Forward / Rewind Time: | 65 sec. (C-60) |
Noise Reduction: | Dolby-B, Double Dolby NR Circuits |
Frequency Response: | 20Hz to 22kHz (Metal) 20Hz to 21kHz (FeCr) 20Hz to 20kHz (CrO2) 20Hz to 18kHz (Normal) |
Signal to Noise Ratio: | 68dB (dolby NR on WTD) 55dB (dolby NR off WTD) |
Wow and Flutter: | 0.035% (wrms) |
Total Harmonic Distortion: | 0.9% (1kHz Dolby level) |
Bias Frequency: | 105kHz |
Input Sensitivity / Impedance: | 100mV / 50kOhm (line) 0.25mV / 200 Ohm (mic) |
Output: | 1V / 50kOhm (line) 2mV / 8Ohm (headphone) |
Preamplifier: | Output-Level Control Headphone Volume Control Individual Input Level Controls Master Record Level Control Microphone Level Adjust (Left/Right) |
Calibration: | 10kHz Test Tone 400Hz Test Tone Manual Bias Calibration Manual Level Calibration |
Power Source: | 220V / 50Hz, 120V / 60Hz (for USA and Canada), 240V / 50Hz (For UK) |
Power Consumption: | 40W |
Semiconductors: | 128 x transistors, 6 x IC, 90 x diodes, 3 x zener diodes |
Dimensions (W x H x D): | 455 x 120 x 300mm |
Weight: | 8.7kg |
Year: | 1980 |
