Type: | 3-head, single compact cassette deck |
Track System: | 4-track, 2-channel stereo |
Tape Speed: | 4.75 cm/s |
Rewing time for C-60: | Less than 35 s (variable speed for fast forward and rewind) |
Heads: | 1 x record, 1 x playback, 1 x erase |
Tape Type: | Type I, CrO2, Metal |
Noise Reduction: | Dolby-NR, MPX Filter, Telefunken HighCom |
Frequency Response: | 20Hz to 22kHz (Metal) 20Hz to 22kHz (CrO2) 20Hz to 20kHz (FeCr) |
Signal to Noise Ratio: | 78dB (Metal tape, High Com) 76dB (CrO2 tape, High Com) 75dB (FeCr tape, High Com) |
Bias Frequency: | 100kHz (nominal) |
Wow and Flutter: | 0.035% (wrms) |
Preamplifier: | Output-Level Control Individual Input Level Controls Master Record Level Control |
Calibration: | 400Hz Test Tone Auto Bias Calibration Auto Level Calibration |
Display: | 4-Digıt Digital Counter Digital Peak-Reading Meters |
Input: | 100mV (line 1/2) 2mV (microphone near) 0.2mV (microphone distant) |
Output: | 0.775V / 100 Ohm (line) |
Headphone Output Matching: | 8 – 2,000 ohms, 3.5mm stereo jack |
Power Requirements: | 110/250V switchable, 50/60Hz |
Power consumption: | 50W |
Electronic components: | 42 integrated circuits, 155 transistors, 8 FET’s, 3 phototransistors, 7 LED’s, 125 diodes, 16 zener diodes |
Dimensions (W x D x H): | 455 x 330 x 177mm |
Weight: | 12kg |
Year: | 1979 |
