Type: | 3-head, single compact cassette deck |
Track System: | 4-track, 2-channel stereo |
Tape Speed: | 4.76 cm/s |
Heads: | 1 x combination record/playback GX head 1 x erase GX head |
Motor: | 2 x reel 1 x capstan |
Fast Forward/Rewind Time: | 60 to 80 seconds (variable) using a C-60 Cassette tape |
Tape Type: | Type I, CrO2, FeCr |
Noise Reduction: | B |
Frequency Response: | 30 Hz to 15 kHz (±3 dB, low noise tape) 35Hz to 19kHz (±3 dB, FeCr tape) 30 Hz to 16 kHz (±3 dB, CrO₂ tape) |
Signal to Noise Ratio: | 62dB (dolby B) |
Wow and Flutter: | 0.06% |
Total Harmonic Distortion: | 1.5% |
Input: | Microphone - 0,25mV Line - 70mV |
Output: | Line - 0,775V |
Semiconductors: | 98 x transistors 112 x diodes 4 x FET 17 x IC |
Power requirement: | 110V to 240V, 50/60Hz (switchable) |
Optional Accessories: | RC-17 or RC-18 Remote Control |
Dimensions (W x H x D): | 440 x 255 x 225mm |
Weight: | 13.5kg |
