Type: | Stereo cassette deck |
Track system: | Compact cassette / stereo |
Wow Flutter: | 0.025% WRMS (JIS) ± 0.05% Wpeak (EIAJ |
Frequency response: | 20 Hz to 18 kHz ± 3 dB (Normal tape) 20 Hz to 19 kHz ± 3 dB (CrO 2 tape) 20 Hz to 21 kHz ± 3 dB (Metal tape) |
Distortion factor (1 kHz, 0 VU): | 0.7% (Metal tape) |
S/N ratio (Metal tape): | 60 dB (3% THD level WTD) 56 dB (EIAJ) |
Dolby B on: | 5dB at 1kHz, 10dB improvement at 5kHz or more |
Dolby C on: | 15 dB at 500 Hz, 20 dB improvement at 1 kHz |
Heads: | Super GX recording head × 1 Super GX playhead × 1 Erasing head × 1 |
For motor capstan: | Quartz lock PLL servo DD motor |
For reel: | DC motor |
Fast winding time: | About 90 seconds (using C-60 tape) |
Input level Line: | 70mV / 47kΩ |
Output level Line: | 410mV / 2kΩ or less |
Headphone: | 1.3mW / 8Ω |
Power supply voltage: | AC 100V, 50Hz / 60Hz |
Power consumption: | 39W |
Maximum external dimensions (EIAJ): | 440 × 100 × 363mm |
Weight Approximately: | 9.8 kg |
Optional: | Wired remote control RC-31 (\ 6,000) Wireless remote control RC-91 (\ 18,000) |
Year: | 1982 |
