Type: | 3-head, single compact cassette deck |
Track System: | 4-track, 2-channel stereo |
Tape Speed: |
4.8 cm/s |
Heads: | 1 x combination record/playback 1 x erase |
Motor: | 1 x DC servo |
Tape Type: | Normal, CrO2, Metal |
Noise Reduction: | B, C |
Frequency Response: | 20Hz to 19kHz (Metal tape) |
Signal to Noise Ratio: | 68dB (dolby C) |
Wow and Flutter: | 0.035% |
Total Harmonic Distortion: | 1.5% |
Input: | 50mV (line) 0.3mV (mic) |
Output: | 0.55V (line) |
Semiconductors: | 8 x IC 90 x transistors 75 x diodes 37 x LED |
Power supply: | AC 120V / 60Hz |
Power Consumption: | 17W |
Dimensions (W x H x D): | 420 x 110 x 280mm |
Weight: | 4kg |
Year: | 1981 |
