SONY CFS-99
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco
Type: | FM / MW Stereo Cassette Corder |
[Radio section] | Frequency range: 88 to 108MHz (FM) 530 to 1605 kHz (AM) |
[Antennas] | FM: Telescopic antenna FM: 75Ω external antenna jack (Mini-jack) AM: Built-in ferrite bar antenna |
[Tape recorder section and general] | Recording system: 4-track, 2-channel stereo Tape speed: 4.8 cm / s Fast winding time: Approx. 1 min. 30 sec. with Sony Cassette C-60 Frequency response: 30 to 13kHz with standard cassette, with the Normal button depressed 30 to 14kHz with chromium dioxide cassette, with the Cr02 button depressed 30 to 15kHz with Sony metal cassette, with the Metal button depressed S/N: 46dB Wow and flutter: 0.075% (WRMS) Speakers: Two-way Woofer: Approx.20 cm (7-3/4") Tweeter: Approx. 5cm (2") |
[Inputs sensitivity / impedance] | MIC1, 2: 0.2mV (-72dB) / low impedance Line1, 2: 0.25V (-10dB) / 47kΩ (With Line In / Phono selector set to Line In) 2.8mV (-49dB) / 47kΩ (With Line In / Phono selector set to Phono) |
Outputs level / impedance: | 0.44V (-5dB) / 10kΩ or higher (Line) 3.2 to 8Ω (External speaker x 2) 8Ω (Headphones) |
Power requirements: | AC 120V, 60Hz DC 15V, 10 batteries size D (IEC designation R20) |
Power consumption: | 26W |
Year: | 1981 |
