Type: | Mono Power Amplifier |
RMS Power Output (8/4/2 ohms): | 1,200W min. sine wave continuous average power output from 20Hz to 20kHz |
Output Load Impedance: | Terminals for 8, 4, or 2 ohms |
Rated Power Band: | 20Hz to 20kHz |
Total Harmonic Distortion: | 0.005% max. at any level from 250mW to rated power output |
Intermodulation Distortion: | SMPTE 0.005% maximum if instantaneous peak output does not exceed twice the output rating |
Dynamic Headroom: | 2.1dB |
Frequency Response: | 20Hz to 20kHz, +0 / -0.25dB 10Hz to 100kHz, +0 / -3.0dB |
Input Sensitivity: | 2.45V Unbalanced 4.9V Balanced |
A-Weighted Signal-to-Noise Ratio: | Balanced – 97dB (124dB below rated output) Unbalanced – 93dB (120dB below rated output) |
Wide Band Damping Factor: | >100 (8 ohms) |
Input Impedance: | 10 kohms |
Power Guard®: | Clipping is prevented and THD does not exceed 2% with up to14dB overdrive at 1kHz |
Power Requirements: | 100V, 50/60Hz at 18A 110V, 50/60Hz at 16.5A 120V, 50/60Hz at 15A 220V, 50/60Hz at 8.2A 230V, 50/60Hz at 7.8A 240V, 50/60Hz at 7.5A |
Dimensions (H x W x D): | 11 x 17.75 x 19.63Inch (27.9 x 45 x 49.9cm) |
Weight: | 147 lbs. (66.8kg) net 172 lbs. (78.2kg) boxed |
Year: | 2000 |
