Type: | Monoblock Power Amplifier |
[Power Output] | |
Minimum sine wave continuous average power output is: | 1,200 watts into 2 ohm load 1,200 watts into 4 ohm load 1,200 watts into 8 ohm load |
Output Load Impedance: | 2, 4 or 8 ohms |
Total Harmonic Distortion: | 0.005% maximum harmonic distortion at any power level from 250 milliwatts to rated power, 20Hz to 20,000Hz |
Rated Power Band: | 20Hz to 20,000Hz |
Frequency Response: | +0, -0.25dB from 20Hz to 20,000Hz +0, -3dB from 10Hz to 100,000Hz |
Input Sensitivity (for rated output): | 2.5 Volt Unbalanced 5 Volt Balanced |
Outputs: | XLR |
Signal To Noise Ratio (A-Weighted): | 120dB below rated output, Unbalanced 124dB below rated output, Balanced |
Intermodulation Distortion: | 0.005% maximum, if the instantaneous peak power output does not exceed twice the rated power output for any combination of frequencies from 20Hz to 20,000Hz |
Wide Band Damping Factor: | Greater than 40 |
Input Impedance: | 10 kohms |
Power Guard: | Less than 2% THD with up to 14dB overdrive at 1,000Hz |
Power Requirements: [Note: Refer to the rear panel of the MC1.2KW for the correct voltage] | 100 Volts, 50/60Hz at 15 Amps 110 Volts, 50/60Hz at 12.5 Amps 120 Volts, 50/60Hz at 12 Amps 220 Volts, 50/60Hz at 7.5 Amps 230 Volts, 50/60Hz at 6.5 Amps 240 Volts, 50/60Hz at 6.5 Amps |
Standby: | 0.5 watts |
Overall Dimensions: | Width is 17 3⁄4 inches (45.09cm) Height is 12 5⁄16 inches (31.27cm) including feet Depth is 22 inches (55.88cm) including the Front Panel and Cables |
Weight: | 147 pounds (66.7 kg) net 172 pounds (78.0 kg) in shipping carton |
Year: | 2007 - 2010 |
