Type: | Stereo power amplifier |
[Succession effective output] | |
At the time of a stereo: | 230W+230W (4ohms) 150W+150W (8ohms) |
At the time of a monophonic recording: | 460W (8ohms) |
Input sensitivity: | 1V/150W (8ohms) 1V/100W (8 ohms, reference position) |
Input impedance: | Coaxial - 45kohm Balance - 66kohm |
Gain: | 32dB |
Total harmonic distortion factor: | 0.004% (1kHz, 8ohms) 0.03% (20Hz - 20kHz, 8ohms) |
S/N ratio: | 115dB (1kHz, IHF-A) |
Supply voltage: | AC100V, 50Hz / 60Hz |
Power consumption: | 350W (Electrical Appliance and Material Control Law) |
Dimensions (W x H x D): | 467x 212x 440mm |
Weight: | 26.5kg |
Year: | 1996 |
[Remark] | |
Upgrade to M-7i: | ¥ 50,000 |
