Type: | Stereo power amplifier |
Effective output: | Class A - 105W + 105W (8Ω, 20Hz to 20kHz, both channel operation) At the time of BTL connection (AB class) - 400W (Class A up to 105W, 8Ω, 20Hz to 20kHz) |
Total harmonic distortion rate: | 0.008% or less (8Ω, both channel operation) 0.01% (4Ω, both channel operation) |
Intermodulation distortion rate: | 0.008% or less (8Ω, 60Hz: 7kHz = 4: 1) |
Frequency response: | 10Hz to 100kHz (-0.5dB) |
Input sensitivity: | 750mV |
Input impedance Direct in: | 300kΩ |
ATT in: | 45kΩ |
S/N ratio (IHF-A correction): | 120dB |
Power supply: | AC 100V, 50Hz / 60Hz |
Power consumption: | 540W (Electrical Appliance and Material Control Law) |
Accessory devices: | Peak hold with peak hold (with meter OFF SW) Electro Static terminal for speaker Signal OFF switch 3 step switching FAN switch Line Phase Sensor BTL connection switch Subsonic filter (15Hz, -6dB / oct) Input attenuator Warm-up mechanism Preheating mechanism Protection circuit DC drift detection Speaker protection circuit Overcurrent detection amplifier protection circuit Temperature detection amplifier protection circuit |
Optional: | Special wood case W - 05 M (\ 60,000¥) Rack mount adapter LM - 05 M (\ 15,000¥) |
External dimensions (W x H x D): | 460 × 210 × 437mm |
Weight: | 40kg |
