Type: | Mono Power Amplifier |
Continuous effective output: | 1000W (4Ω) 500W (8Ω) |
Input sensitivity: | 1V / 500W (8Ω) |
Input impedance Coaxial: | 50kΩ |
Balance: | 100kΩ |
Total harmonic distortion factor: | 0.04% (20Hz to 20kHz) |
Gain (gain): | 36dB |
Frequency response: | 20Hz to 20000Hz (+0 - 0.1 dB) 10Hz to 100,000Hz (+0 -1.0 dB) |
S/N ratio (IHF-A): | 115dB |
Attachment: | Device Coaxial-Balance input attenuator Line Phase Sensor |
Power supply voltage: | AC 100V, 50Hz / 60Hz |
Power consumption: | 560W (Electrical Appliance and Material Control Law) |
External dimensions (W x H x D): | 467 × 233 × 482mm |
Weight: | 43.5kg |
Year: | 1995 |
