Type: | Class-A stereo tube amplifier |
Effective output: | 2,5W+2,5W (8ohm, 1kHz, 10% THD) |
Maximum output: | 3W + 3W (8ohm, 1kHz) |
Treble: | 10kHz, +6,0dB -6,0dB |
Bass: | 100Hz, +6,0dB -6,0dB |
Frequency characteristic: | 30Hz - 15kHz, +2dB, -3dB (1W/8ohm) |
Input sensitivity: | Phono - 5mV (1kHz, 2,5W, 8ohm) Line input - 250mV (1kHz, 2,5W, 8ohm) Instrument - 30mV (1kHz, 2,5W, 8ohm) |
Input terminals: | Line input - RCA (L/R) Phono - RCA (L/R) Line input - 3,5mm (mini-jack, L/R) Instrument - 6,5mm (jack) |
Output-terminals: | REC OUT - RCA (L/R) Phones - 3,5mm (mini-jack, L/R) Speaker (8ohm, L/R) |
Pre-Amp Tubes: | 12AX7/ECC83 x 2 pieces |
Output Tubes: | 6BQ5/EL84 x 2 pieces |
Power supply: | AC 100V, 50/60Hz |
Power consumption: | 62W |
Dimensions (W x H x D): | 210 x 185 x 330mm |
Weight: | 8.2kg |
