Type: | Stereo power amplifier |
[Continuation average output] | |
At the time of stereo specification: | 300 W/ch (2ohms) 250 W/ch (4ohms) 170 W/ch (8ohms) 85 W/ch (16ohms) (20Hz - 20kHz, 0.01% of distortion) |
At the time of monophonic specification: | 600W (4ohms) 500W (8ohms) 340W (16ohms) (bridge connection) |
IM distortion (EIA): | 0.003% |
[THD] | |
At the time of stereo specification: | 0.01% (2 - 16ohms load) |
At the time of monophonic specification: | 0.01% (4 - 16ohms load, bridge connection) |
Frequency response: | 20Hz-20kHz, +0 -0.2dB (at the time of a continuation average output level control MAX) 0.5Hz-250kHz, +0 -3dB (at the time of 1W output level control MAX) 0.5Hz-150kHz, +0 -3dB (at the time of 1W output level-control 6dB) |
Gain: | 28dB (at the time of a stereo / monophonic specification) |
Load impedance: | At the time of stereo specification - 2-16ohms At the time of monophonic specification - 4-16ohms |
Dumping factor (EIA 50Hz): | At the time of stereo specification - 300 At the time of monophonic specification - 150 |
S / N (the time of A compensation): | 120dB (at the time of input short-circuit and a continuation average output) 100dB (at input 1kohm, the time of 1W output EIA) |
Power supply voltage: | AC 100 / 117 / 220 / 240V, 50Hz/60Hz |
Power consumption: | 78W (at the time of no inputting) 560W (8-ohm Output power) |
Option: | Wood cabinet A-8 (16,000yen) |
Dimensions: (W x H x D): | 445 x 160 x 373mm |
Weight: | 23kg |
Year: | 1984 |
